Balanset-1A: Revolutionary Compact Balancer & Vibration Analyzer
Industrial-grade Dynamic Balancing Solution
Balanset-1A represents an advanced solution for rotor balancing of rotors in their own bearings, engineered by Estonian company Vibromera OU. The device offers professional equipment balancing at €1,751, which is substantially less expensive than traditional vibration analyzers while retaining high measurement accuracy. The system enables on-site balancing directly at the equipment's working position without requiring removal, which is critically important for reducing production downtime.
About the Manufacturer
Vibromera OU is an Estonian company concentrating in the development and production of devices for technical diagnostics of industrial equipment. The company is incorporated in Estonia (registration number 14317077) and has branches in Portugal.
Contact Information:
Official website: https://vibromera.eu/shop/2/
Technical Specifications
Detection Parameters
Balanset-1A delivers precise measurements using a twin-channel vibration analysis system. The device measures RMS vibration velocity in the range of 0-80 mm/s with an accuracy of ±(0.1 + 0.1?Vi) mm/s. The functional frequency range is 5-550 Hz with possible extension to 1000 Hz. The system supports rotation frequency measurement from 250 to 90,000 RPM with phase angle determination accuracy of ±1 degree.
Operating Principle
The device uses phase-sensitive vibration measurement technology with MEMS accelerometers ADXL335 and laser tachometry. Two mono-directional accelerometers measure mechanical oscillations proportional to acceleration, while a laser tachometer generates impulse signals for determining rotational speed and phase angle. Digital signal processing includes FFT analysis for frequency analysis and proprietary algorithms for automatic computation of correction masses.
Full Kit Package
The standard Balanset-1A delivery includes:
Measurement unit with USB interface - primary module with embedded preamplifiers, integrators, and ADC
2 vibration sensors (accelerometers) with 4m cables (alternatively 10m)
Optical sensor (laser tachometer) with 50-500mm measuring distance
Magnetic stand for sensor mounting
Electronic scales for exact measurement of corrective masses
Software for Windows 7-11 (32/64-bit)
Plastic transport case
Complete set of cables and documentation
Functional Capabilities
Vibrometer Mode
Balanset-1A operates as a comprehensive vibration analyzer with abilities for measuring overall vibration level, FFT spectrum analysis up to 1000 Hz, determining amplitude and phase of the fundamental frequency (1x), and continuous data recording. The system delivers visualization of time signals and spectral analysis for equipment condition diagnostics.
Balancing Mode
The device supports one-plane (static) and two-plane (dynamic) balancing with automatic calculation of corrective masses and their installation angles. The unique influence coefficient saving function allows considerable acceleration of repeat balancing of similar equipment. A dedicated grinding wheel balancing mode uses the three-correction-weight method.
Software
The easy-to-use program interface provides step-by-step guidance through the balancing process, making the device accessible to personnel without specific training. Key functions include:
Automatic tolerance calculation per ISO 1940
Polar diagrams for imbalance visualization
Result archiving with report generation capability
Metric and imperial system support
Multilingual interface (English, German, French, Polish, Russian)
Usage Domains and Equipment Types
Industrial Equipment
Balanset-1A is efficiently applied for balancing fans (centrifugal, axial), pumps (hydraulic, centrifugal), turbines (steam, gas), centrifuges, compressors, and electric motors. In manufacturing facilities, the device is used for balancing grinding wheels, machine spindles, and drive shafts.
Agricultural Machinery
The device provides special value for agriculture, where continuous operation during season is critically important. Balanset-1A is applied for balancing combine threshing drums, shredders, mulchers, mowers, and augers. The ability to balance on-site without equipment disassembly permits eliminating costly downtime during peak harvest periods.
Specialized Equipment
The device is effectively used for balancing crushers of various types, turbochargers, drone propellers, and other high-speed equipment. The speed frequency range from 250 to 90,000 RPM covers essentially all types of industrial equipment.
Benefits Over Alternatives
Economic Value
At a price of €1,751, Balanset-1A provides the functionality of devices costing €10,000-25,000. The investment pays for itself after preventing just 2-3 bearing failures. Savings on third-party balancing specialist services amounts to thousands of euros annually.
Ease of Use
Unlike sophisticated vibration analyzers requiring months of training, mastering Balanset-1A takes 3-4 hours. The step-by-step guide in the software allows professional balancing by personnel without specialized vibration diagnostics training.
Portability and Autonomy
The complete kit weighs only 4 kg, with power supplied through the laptop's USB port. This enables balancing in outdoor conditions, at isolated sites, and in inaccessible locations without additional power supply.
Versatile Application
One device is appropriate for balancing the broadest spectrum of equipment - from small electric motors to large industrial fans and turbines. Support for single and dual-plane balancing covers all typical tasks.
Real Application Results
Drone Propeller Balancing
A user achieved vibration reduction from 0.74 mm/s to 0.014 mm/s - a 50-fold improvement. This demonstrates the remarkable accuracy of the device even on small rotors.
Shopping Center Ventilation Systems
Engineers effectively balanced radial fans, achieving decreased energy consumption, removed excessive noise, and prolonged equipment lifespan. Energy savings recovered the device cost within several months.
Agricultural Equipment
Farmers note that Balanset-1A has become an indispensable tool preventing costly breakdowns during peak season. Lower vibration of threshing drums led to lower fuel consumption and bearing wear.
Cost and Delivery Terms
Current Prices
Complete Balanset-1A Kit: €1,751
OEM Kit (without case, stand, and scales): €1,561
Special Offer: €50 discount for newsletter subscribers
Wholesale Discounts: up to 15% for orders of 4+ units
Acquisition Options
Official Website: vibromera.eu (recommended)
eBay: trusted sellers with 100% rating
Industrial Distributors: through B2B channels
Payment and Shipping Terms
Payment Methods: PayPal, credit cards, bank transfer
Shipping: 10-20 business days by international mail
Shipping Cost: from $10 (economy) to $95 (express)
Warranty: manufacturer's warranty
Technical Support: included in price
Final Assessment
Balanset-1A represents an optimal solution for organizations striving to establish an successful equipment balancing system without major capital expenditure. The device opens up access to professional balancing, allowing small businesses and service centers to deliver services at the level of large industrial companies.
The blend of affordable price, ease of use, and professional functionality makes Balanset-1A an vital tool for modern technical maintenance. Investment in this device is an investment in equipment reliability, reduced operating costs, and enhanced competitiveness of your enterprise.
|
|
